Bench Top Shaper Router Table SCHEPPACH Hf60

The compact HF60 wood milling machine from Scheppach is a practical table model that can also be used on the move if required.
The table milling machine has a firm footing thanks to its stable construction and its own weight of almost 21 kg.
Due to the table extensions on both sides, the compactly designed milling machine offers a large area for working.

• Compact tabletop model
• Variable speed control from 11500 to 24000 rpm
• Collets with diameters of 6, 8 and 12 mm
• Powerful 1500-watt engine
• Comes with angular stop and large aluminium stops as standard
• Table width extensions on both sides, table size 610 x 360 mm
• Spindle height adjustable from 0 to 40 mm

Bench milling machines are often used in hobby workshops, for example to make slots, grooves or other recesses. The HF60 from scheppach is a practical and compact table model that can even be used as a mobile device if required.

The HF60 is suitable for use with milling cutters up to a maximum diameter of 50 mm. The stable construction and a weight of almost 21 kg ensure that the wood milling machine is particularly stable and secure.

With a table size of 610 x 360 mm, the wood milling machine can also be used in small workshops. The table extensions integrated on both sides also enlarge the table surface and thus also enable the processing of large workpieces and the execution of special milling work.

The spindle height and thus the height of the cutter blade is easily adjusted by turning a hand crank on the side of the machine. The desired height can be adjusted from 0-40 mm and is then fixed with a clamping screw. To fix the workpieces on the milling table, three clamping devices with 6, 8 and 12 mm are included in the scope of delivery. This enables good guidance and safe handling.

Thanks to the variable speed control from 11500 to 24000 revolutions per minute, the workpiece can be optimally processed. The 1500 W motor also ensures sufficient power.

The HF60 is also equipped as standard with an angle stop and particularly large aluminum stops that hold the workpiece in place.

Technical data:

Dimensions L x W x H 1030 x 450 x 530 mm
Table size 610 x 360 mm
Speed 11500 – 24000 rpm
Spindle height 0 – 40 mm
Table inserts 32 / 47.5 / 55 / 75 mm
Motor 230 – 240 V~ / 50 Hz
Input 1500 W
Weight net / gross 20.5 / 24 kg
Packaging dimensions 670 x 535 x 390 mm
