230V CIRCULAR PLUNGE SAW 210MM WITH GUIDE RAIL AND ACCESSORIES SCHEPPACH PL75

230V CIRCULAR PLUNGE SAW 210 MM WITH GUIDE RAIL AND ACCESSORIES SCHEPPACH PL75

WHEN USED IN CONJUNCTION WITH THE OPTIONAL 1400 MM GUIDE RAIL THE SCHEPPACH PL75 NOW BECOMES A 3 IN 1 PLUNGE SAW SYSTEM WHICH ALLOWS YOU TO COMPLETE A VARIETY OF PRECISION CUTS WHICH ARE IMPOSSIBLE WITH A TRADITIONAL ELECTRIC HANDSAW.  CHOOSE A PL75 PACKAGE AND REALISE YOUR POTENTIAL.

• Powerful 1600 Watt motor
• The parallel plunge cutting system maintains constant and smooth position whilst sawing
• The standard 36 tooth TCT saw blade gives a fine and accurate finish being complemented with the spring loaded riving knife for unimpeded plunge cuts
• Enclosed guard system provides excellent dust extraction (extractor not provided)
• 75 mm depth of cut allows trimming and sizing of doors etc. plus the cutting capacity for those bigger projects when required
• Suitable for boards and solid wood
• Flush cuts to within 16 mm
• Everyone can achieve professional results with PL75
• In the workshop or on site
• 3 m rubber cable
• Tilt safety device included. Prevents the saw from tipping when in tilt mode
• Includes 1400 mm Rail, clamps, rail connector and anti tip

3 IN 1:
Plunge saw
Hand held circular saw
Panel sizing saw

PL75 is ideal for edging up to 16 mm from the wall. One more diverse operation from this unique saw. Standard attachable splinter guards. Perfect for splinter free cuts on MDF and cabinet grade veneered boards etc.

Mitre cuts with stepless angle adjustment from 0° to 45°. Inclusive tilt safety device – prevents saw tipping in tilt mode.

Massive 75 mm depth of cut equal to cutting capacity of many circular saw benches. Perfect parallel cutting every time.

Perfect for kitchen worktops. Only possible with a plunge saw system splinter-free. Even an amateur can achieve exact parallel splinter free cuts using the PL75 with optional guide track system.

PL75 ideal whatever the material:
• solid natural timbers
• chipboard
• plywood
• even MDF and double coated boards …

Retractable riving knife for unimpeded plunge cuts. Splinter-free edges thanks attachable splinter guard.

Technical data:

Dimensions: LxWxH 420 x 300 x 235 mm
Blade: Ø 210 mm
Arbor: Ø 30 mm
Blade speed: 4500 rpm
Max. cut: 90° 75 mm
Max. cut: 45° 55 mm
Bevel capacity: 0 – 45°
Distance-to-wall cut: 16 mm
Dust collection Ø: inner/outer 35/38 mm
Motor: 230 – 240 V~
Input: 1600 W
Weight net / gross: 6.9 / 7.6 kg
Packaging dimensions: 430 x 240 x 315 mm
